XXS | XS | S | M | L | XL | |
---|---|---|---|---|---|---|
Długość korby | 170MM | 170MM | 170MM | 170MM | 175MM | 175MM |
Długość wspornia kierownicy | 60mm | 60mm | 75mm | 75mm | 90mm | 110mm |
Długość wspornika siodła | 300mm | 300mm | 350mm | 350mm | 400mm | 400mm |
Szerokość siodła | 155mm | 155mm | 155mm | 143mm | 143mm | 143mm |
Szerokość kierownicy | 580mm | 580mm | 600mm | 600mm | 620mm | 620mm |
Reach | 373mm | 388mm | 393mm | 398mm | 402mm | 414mm |
Stack | 536mm | 555mm | 562mm | 593mm | 608mm | 632mm |
Baza kół | 1036mm | 1053mm | 1061mm | 1066mm | 1075mm | 1096mm |
Przekrok | 692mm | 715mm | 745mm | 775mm | 805mm | 827mm |
Wysokość główki ramy | 121mm | 139mm | 147mm | 175mm | 191mm | 217mm |
Front-Center | 605mm | 622mm | 630mm | 635mm | 645mm | 665mm |
Fork Rake/Offset | 51mm | 51mm | 51mm | 51mm | 51mm | 51mm |
Kąt główki ramy | 69.5° | 70° | 70° | 71° | 71° | 71° |
Trail | 75mm | 72mm | 72mm | 65mm | 65mm | 65mm |
Chain-Stay Length | 440mm | 440mm | 440mm | 440mm | 440mm | 440mm |
B-B Height | 278mm | 278mm | 278mm | 278mm | 278mm | 278mm |
Seat-Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
Fork Length (full) | 395mm | 395mm | 395mm | 395mm | 395mm | 395mm |
B-B Drop | 70mm | 70mm | 70mm | 70mm | 70mm | 70mm |
Długość podsiodłowej rury ramy | 360mm | 395mm | 440mm | 470mm | 510mm | 530mm |
Efektywna długość górnej rury ramy | 531mm | 552mm | 559mm | 573mm | 582mm | 601mm |
